Shredder – Tractor PTO operated type
KEW make Tractor PTO operated type Shredder is suitable to shred the agricultural waste like arecanut trees, Coconut fronds, palm tree fronds, pruned tree branches (upto 100 mm Diameter), Tapioca, Mulberry plants, harvested banana trees and papaya trees etc.,
It consists of feeding chute, outlet mouth, rotor assembly with 6 nos. of partially tapered 12 mm thickness blades.
The entire rotor assembly is covered by 4 mm thickness top cover.
A 12mm thickness flat blade is fixed on the top frame which is mounted on the inlet chute side.
The propeller shaft takes drive from PTO shaft of the tractor and transmits power to the machine.
Three Point Linkage is provided in the machine for the stability during operation and transportation of the unit.
Pneumatic Wheels with axle and towbar can also be provided on customer’s request for the transportation purpose.
FEATURES :
- » Agricultural farm waste both dry and wet can be converted into organic manure by the way of shredding them into small pieces and getting them decomposed.
- » The shredded waste can be spread on the field as organic manure to increase the moisture content, and fertility of the soil, simultaneously reducing the usage of chemical fertilizers.
- » The shredding efficiency is 100%.
- » This machine is also suitable for preparing vermi compost.
Specification :
| Type | Tractor PTO operated | ||
| Overall Dimension | Length 1450mm x Width 1275mm x Height 1075mm | ||
| Weight | 340 Kg (approximate) | ||
| Output Capacity | 2000 – 2700 kg / hour (approximate) | ||
| Power requirement | 35 HP above | ||
| Transporting Unit | 3 point linkage arrangement or 2 Nos. of Pneumatic wheels with axle and towbar (on customer’s choice) |
Shredder - Mini-Tractor PTO operated type
KEW make Mini-Tractor PTO operated type Shredder is suitable to shred the agricultural waste like Coconut tree fronds, arecanut tree fronds, palm tree fronds, pruned tree branches (upto 50 mm Diameter), Tapioca, Mulberry plants, papaya trees etc.,
It consists of feeding chute, outlet mouth, rotor assembly with 4 nos. of partially tapered 12 mm thickness blades.
The entire rotor assembly is covered by 4 mm thickness top cover.
A 12mm thickness flat blade is fixed on the top frame which is mounted on the inlet chute side.
The propeller shaft takes drive from PTO shaft of the tractor and transmits power to the machine.
Pneumatic Wheels with axle and towbar is provided in the machine for the stability during operation and transportation of the unit.
FEATURES :
- » Agricultural farm waste both dry and wet can be converted into organic manure by the way of shredding them into small pieces and getting them decomposed.
- » The shredded waste can be spread on the field as organic manure to increase the moisture content, and fertility of the soil, simultaneously reducing the usage of chemical fertilizers.
- » The shredding efficiency is 100%.
- » This machine is also suitable for preparing vermi compost.
Specification :
| Type | Mini-Tractor PTO operated | ||
| Overall Dimension | Length 0000mm x Width 0000mm x Height 0000mm | ||
| Weight | 000 Kg (approximate) | ||
| Output Capacity | 1000 – 1500 kg / hour (approximate) | ||
| Power requirement | 18 HP above | ||
| Transporting Unit | 2 Nos. of Pneumatic wheels with axle and towbar. |
Shredder cum Pulverizer – Tractor PTO operated type
KEW make Tractor PTO operated type Shredder cum Pulverizer is suitable to shred and pulverize the agricultural waste like Coconut fronds, palm tree fronds, pruned tree branches (upto 100 mm Diameter), Tapioca, Mulberry plants, harvested banana trees, papaya trees and arecanut trees etc.,
It consists of feeding chute, outlet mouth, rotor assembly with 6 nos. of partially tapered 12 mm thickness blades mounted on one side and 48 nos. of small rectangular 10 mm thickness blades mounted on the other side supported by a disc.
The entire rotor assembly is covered by 4 mm thickness top cover.
A 12 mm thickness flat blade is fixed on the top frame which is mounted on the inlet chute side.
The propeller shaft takes drive from PTO shaft of the tractor and transmits power to the machine.
Three Point Linkage is provided in the machine for the stability during operation and transportation of the unit.
Pneumatic Wheels with axle and towbar can also be provided on customer’s request for the transportation purpose.
FEATURES :
- » Agricultural farm waste both dry and wet can be converted into organic manure by the way of shredding them into small pieces and getting them decomposed.
- » The shredded & pulverized waste can be spread on the field as organic manure to increase the moisture content, and fertility of the soil, simultaneously reducing the usage of chemical fertilizers.
- » The shredding and pulverizing efficiency is 100%.
- » Decomposition period is very quicker due to pulverizing.
- » This machine is also suitable for preparing vermi compost.
Specification :
| Type | Tractor PTO operated | ||
| Overall Dimension | Length 1470mm x Width 1770mm x Height 1050mm | ||
| Weight | 540 Kg (approximate) | ||
| Output Capacity | 2100 – 2500 kg / hour (approximate) | ||
| Power requirement | 45 HP above | ||
| Transporting Unit | 3 point linkage arrangement or 2 Nos. of Pneumatic wheels with axle and towbar (on customer’s choice) |
Shredder cum Pulverizer with Elevator
KEW make Tractor PTO operated type Shredder cum Pulverizer with Elevator is suitable to shred and pulverize the agricultural waste like Coconut tree fronds, palm tree fronds, pruned tree branches (upto 100 mm Diameter), Tapioca, Mulberry plants, harvested banana trees, papaya trees and arecanut trees fronds etc.,
The main purpose of this elevator model is that the chaff can be loaded in the trolley without manpower.
It consists of feeding chute, outlet mouth, rotor assembly with 6 nos. of partially tapered 4mm/8mm thickness blades mounted on one side and 48 nos. of small rectangular 10 mm thickness blades mounted on the other side supported by a disc.
The entire rotor assembly is covered by 4 mm thickness top cover.
A 12 mm thickness flat blade is fixed on the top frame which is mounted on the inlet chute side.
The propeller shaft takes drive from PTO shaft of the tractor and transmits power to the machine.
Three Point Linkage is provided in the machine for the stability during operation and transportation of the unit.
2 Nos. of Pneumatic Wheels with axle is provided for transportating the machine to any part of the field.
FEATURES :
- » Agricultural farm waste both dry and wet can be converted into organic manure by the way of shredding them into small pieces and getting them decomposed.
- » The shredded & pulverized waste can be spread on the field as organic manure to increase the moisture content, and fertility of the soil, simultaneously reducing the usage of chemical fertilizers.
- » The shredding and pulverizing efficiency is 100%.
- » Decomposition period is very quicker due to pulverizing.
- » This machine is also suitable for preparing vermi compost.
Specification :
| Type | Elevator Model Tractor PTO operated | ||
| Overall Dimension | Length 2400mm x Width 2200mm x Height 2500mm | ||
| Weight | 700 Kgs (approximate) | ||
| Output Capacity | 2100 – 2500 kg / hour (approximate) | ||
| Power requirement | 50 HP above | ||
| Transporting Unit | 2 Nos. of Pneumatic wheels with axle and tow bar. |
